1500VA 8 outlet 865W battery backup with APC PowerChute Personal Edition with up to 90 minutes of backup time. Add an extra battery (BR24BP) for up to 360 Minutes RuntimeLearn more about the product
Battery-protected and surge-only outlets - Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment
Cold-start capable - Provides temporary battery power when the utility power is out.
Serial Connectivity - Use any Home Automation network to monitor and control the S20 through its RS-232 serial port. For information on how to communicate with the S20, see APC's Application Note #102. Crestron and AMX installers should visit their respective websites for information on how to integrate the S20 into those networks.
Hot-swappable batteries - Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Disconnected battery notification - Warns when a battery is not available to provide backup power.
Dataline Surge Protection - Provides protection of connected equipment from power surges on the data lines.
Automatic self-test - Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Adjustable voltage-transfer points - Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Adjustable voltage sensitivity - Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Audible Alarms - Provides notification of changing utility power and UPS conditions.
User-replaceable batteries - Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
USB Connectivity - Provides management of the UPS via a USB port (not available on all models).
Serial Connectivity - Provides management of the UPS via a serial port.
Transformer-block spaced outlets - Protect equipment with input transformer blocks without blocking access to other receptacles.
Boost and Trim Automatic Voltage Regulation (AVR) - Gives higher application availability by correcting low and high voltage conditions without using the battery.
Intelligent battery management - Maximizes battery performance, life, and reliability through intelligent, precision charging.
Safety-agency approved - Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. UL, FCC, CE, C-Tick approvals.
Lifetime data recovery warranty - Provides peace of mind by providing professional data recovery services in the event data is lost due to the failure of the unit.
Adjustable voltage sensitivity - Provides the ability to adapt the Power Conditioner for optimal performance in specific power environments or generator applications.
Battery replacement without tools - Allows quick, easy battery replacement.
LED status indicators - Quickly understand unit and power status with visual indicators.
Back-UPS RS Features & Benefits
Protection
Battery-protected and surge-only outlets - Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment
Boost and Trim Automatic Voltage Regulation (AVR) - Gives higher application availability by correcting low and high voltage conditions without using the battery.
Data line surge protection - Provides protection of connected equipment from power surges on the data lines.
Safety-agency approved - Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. UL, FCC, CE, C-Tick approvals.
Power conditioning - Protects connected loads from surges, spikes, lightning, and other power disturbances.
Convenience
Audible Alarms - Provides notification of changing utility power and UPS conditions.
Automatic restart of loads after UPS shutdown - Automatically starts up the connected equipment upon the return of utility power.
Automatic self-test - Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Battery replacement without tools - Allows quick, easy battery replacement.
LED status indicators - Quickly understand unit and power status with visual indicators.
Cold-start capable - Provides temporary battery power when the utility power is out.
Hot-swappable batteries - Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Resettable circuit breakers - Enables a quick recovery from overload events.
Transformer-block spaced outlets - Protect equipment with input transformer blocks without blocking access to other receptacles.
User-replaceable batteries - Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Manageability
Adjustable voltage sensitivity - Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Adjustable voltage-transfer points - Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Serial Connectivity - Provides management of the UPS via a serial port.
USB Connectivity - Provides management of the UPS via a USB port (not available on all models).
Multiple mounting methods - Allows for standardization on one product for use in different environments.
Intelligent battery management - Micro-processor controlled battery charging and diagnostic testing ensures maximum battery life.
Technical Specifications:
Output
Output Power Capacity: 865 Watts / 1500 VA
Max Configurable Power: 865 Watts / 1500 VA
Nominal Output Voltage: 120V
Output Connections
(2) NEMA 5-15R (Surge Protection)
(6) NEMA 5-15R (Battery Backup)
Input
Nominal Input Voltage: 120V
Input Frequency: 47 - 63 Hz
Input Connections: NEMA 5-15P
Cord Length: 1.83 meters
Input voltage range for main operations: 88 - 148V
Input voltage adjustable range for mains operation: 78 - 152V
