Scale Computing
No Reviews | Add Review

Share Today!


Widget Not Available!!!


Scale Computing’s StorageNodes with ICSTM technology are managed with a simple, easy-to-use UI that takes the hassle and cost out of managing your storage. Create a pool of truly clustered storage by seamlessly adding StorageNodes.
  • MacMall Part #: 8099569
  • Manufacturer Part #: CL3-R2
  • Platform: Universal

Scale Computings StorageNodes with ICSTM technology are managed with a simple, easy-to-use UI that takes the hassle and cost out of managing your storage. Create a pool of truly clustered storage by seamlessly adding StorageNodes. Scales ICS architecture discovers the new node, adds it to the cluster and begins mirroring and
managing your data across the entire cluster. Data migration is history and services dont go down. In fact, you can pull drives out, trip over cords and still not su er services or data access losses.

  • 4 Enterprise-grade SATA Drives
  • Protocol support: iSCSI, NFS, CIFS/SAMBA
  • 150w start-up, 100w operating power
  • (2) GigE ports per appliance
  • Form Factor: 1U
  • Proven HPC le system
  • Web (SSL) for management
  • Serial console for initial set-up only
  • (4) Enterprise-grade SATA drives @ 7200 RPM
  • 210 MB/Sec throughput per (3) node clusters
  • +70 MB/Sec throughput for each additional node

Technical Highlights:
  • Data Protection - All data is mirrored and striped across the nodes in the cluster
  • High Availability - All data is mirrored on at least 2 nodes. This provides continuous uptime if a drive, network port, power supply or even an entire node stops working
  • Scalability - Up to 512 nodes per cluster, more than 2.2 PBs per single le system
  • Compatibility - Nodes of di erent sizes can all participate in the same cluster and be used at full capacity.
    (Limitation: 1 node can not be bigger than 50% of the total cluster capacity)
Storage Area Network Support:
  • SAN Protocols - iSCSI
  • Max LUNs - 255
  • Hosts Supported - Any standards-compliant iSCSI Initiator
  • Security - IP based access control, CHAP Authentication, CRC based connection encryption
  • High Availability - Connections supported to multiple nodes using iSCSI multi-path to connect to the same
Network Attached Storage Support:
  • NAS Protocols - NFS, CIFS
  • Security NFS - IP/Host based access control
  • CIFS - ADS Authentication (Kerberos)
  • High Availability - Virtual IP Addresses are used to serve NAS protocols. In the case of a node/Ethernet failure another node will pick up the down IP and continue communication with the client without losing connectivity
  • Snapshots - True copy-on-write snapshots—instant security, low overhead Flexible snapshot and replication allocation—no need for dedicated snapshot volumes
  • Recovery - Any LUN/Share from any historical snapshot can be restored as a working copy
  • Effciency - Copies changes at a block level (minimizing time and bandwidth)
  • Consistency - Copies point in time snapshots to target cluster
  • Recovery - Any LUN/Share from any available historical snapshot can be restored on the target cluster as a
    working copy
  • Scheduling - Replication can be scheduled as continuous, or in 5 min, 10 min, 15 min, 30 min, 1 hour, 2 hour, 4 hour, 6 hour, 8 hour, 12 hour or daily intervals.
  • Multi-site - Replication can be con gured as a target or a source site for up to 15 other sites simultaneously
  • Management Interface - Serial Console and Flash-based Administrative GUI over https
  • Notification Methods - Email, Syslog
  • Support - Administrator controlled access to the cluster by Scale Support via SSH
  • Upgrades - Upgrades are applied in a rolling fashion to maintain uptime by only removing a single box at a
    time from the cluster

Technical Specs

Packaged Quantity 3 (specifications are for single item)
Device Type NAS server
Host Connectivity Gigabit Ethernet
Enclosure Type Rack-mountable - 1U
Total Storage Capacity 2 TB
Installed Devices / Modules Qty 4 (installed) / 4 (max)
Processor / Memory
Processors Installed 1 x 2.9 GHz
Storage Controller
Max Storage Devices Qty 4
Cache / Buffer Size ( Max ) 4 GB
Hard Drive
Type HDD
Capacity 4 x 1 TB
Interface Type SATA 3Gb/s
Spindle Speed 7200 rpm
Type Network adapter
Data Link Protocol GigE
Network / Transport Protocol iSCSI
Network Services Compatibility Microsoft CIFS, Network File System (NFS)
Features Syslog support, E-mail alert, High Availability
Expansion / Connectivity
Expansion Bays 4 (total) / 0 (free) x external
Interfaces 4 x Ethernet 1000 - RJ-45 ¦ 1 x serial ( management )
Power Device X internal power supply
Installed Qty 2
Power Redundancy Yes
