Eaton Corporation Powerware 9130 1500 VA / 1350W, 120V, 5-15P input, (6) 5-15R Output Tower UPS (PW9130L1500T-XL)

Eaton Corporation
No Reviews | Add Review

Share Today!


Eaton Corporation Powerware 9130 1500 VA / 1350W, 120V, 5-15P input, (6) 5-15R Output Tower UPS

Widget Not Available!!!

Overview

Delivers essential power protection for IT and networking data center equipment, medical systems and manufacturing process control. Provides more real power (watts) to protect more equipment.
  • MacMall Part #: 7682509
  • Manufacturer Part #: PW9130L1500T-XL
  • UPC: 0790341000264
  • Platform: Universal



The Eaton 9130 UPS eliminates all types of utility power problems to supply clean, continuous power to connected equipment. With its rugged design, the 9130 UPS regulates both voltage and frequency to provide the highest grade of UPS protection available. Incorporating more than 40 years of UPS expertise, the 9130 UPS delivers essential power protection for IT and networking data center equipment, medical systems and manufacturing process control. It is also ideal for PBX and VoIP telecommunication equipment. The 9130 UPS is part of the Powerware series.

Key Features:
  • Cuts energy usage and costs with >95% efficiency rating in high efficiency mode
  • Provides more real power (watts) to protect more equipment and leave room for expanding IT systems with a 0.9 power factor
  • Simplifies UPS monitoring and management with a bright LCD user interface, free, intuitive power management software and optional eNotify Remote Monitoring service
  • Increases battery service life and system uptime with ABM battery-charging technology and hot-swappable batteries
  • Extends battery runtime for critical devices with load segments

  • Maximizes runtimes with optional extended battery modules

Technical Specs

General
Device Type UPS - external
Battery Enclosure Type Internal
Color Black
Power Device
UPS Technology On-line
Input Voltage AC 120 V
Input Voltage Range AC 90 - 138 V
Frequency Required 45 - 65 Hz
Input Connector(s) 1 x power NEMA 5-15
Power Output Connectors Details 6 x power NEMA 5-15
Output Voltage AC 120 V ± 3%
Power Capacity 1350 Watt / 1500 VA
Output Waveform Sinewave
Efficiency 95%+
Battery
Type Expandable
Technology Lead acid
Voltage Provided 12 V
Capacity 9 Ah
Run Time (Up To) 7 min at full load ¦ 11 min at 75% load ¦ 18 min at half load ¦ 38 min at 25% load
Networking
Remote Management Interface RS-232, USB
Expansion / Connectivity
Interfaces Management (USB) - 4 pin USB Type B ¦ Management (RS-232) - 9 pin D-Sub (DB-9) ¦ EPO (emergency power off) - terminal block
Expansion Slot(s) 1 (total) / 1 (free) x Communication slot
Miscellaneous
Included Accessories Cable retention brackets
Cables Included 1 x USB cable - external ¦ 1 x power cable - 6 ft
Features LCD display, internal bypass, LED indicators, automatic self-test, Remote Emergency Power Off (REPO), hot-swappable batteries
Compliant Standards FCC Class B certified, UL, VCCI, cUL, EN55022 Class B
Software / System Requirements
Software Included Eaton Intelligent Power Software Suite
Manufacturer Warranty
Service & Support 2 years warranty
Service & Support Details Limited warranty - 2 years
Environmental Parameters
Min Operating Temperature 32 °F
Max Operating Temperature 104 °F
Humidity Range Operating 5 - 90% (non-condensing)
Sound Emission 50 dBA
Dimensions & Weight
Width 6.3 in
Depth 16.9 in
Height 9.1 in
Weight 41.9 lbs
