The Smart-UPS 2200VA LCD 120V from APC provides power to your important computer components in the event of an electrical outage.
MacMall Part #: 8038292
Manufacturer Part #: SMT2200
APC Smart-UPS 2200VA LCD 120V The Smart-UPS 2200VA LCD 120V from APC provides power to your important computer components in the event of an electrical outage. The Uninterruptible Power Supply (UPS) contains a battery which continues to power computers, monitors and other components if the electricity is cut from them. An LCD status display provides information including remaining battery life, load capacity, and event notices. The battery is hot-swappable and easy to replace. An audible alarm alerts you of events like power outage and low battery.
Intuitive LCD Interface Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
Predictive Replace Battery Date Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
InfraStruXure Central Compatible Enables centralized management via APC InfraStruXure Central.
SmartSlot Customize UPS capabilities with management cards.
Cold-Start Capable Provides temporary battery power when the utility power is out.
Serial Connectivity Use any Home Automation network to monitor and control the S20 through its RS-232 serial port.
Resettable Circuit Breakers Enables a quick recovery from overload events.
Hot-Swappable Batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced.
Disconnected Battery Notification Warns when a battery is not available to provide backup power.
Automatic Self-Test Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Automatic Restart of Loads After UPS Shutdown Automatically starts up the connected equipment upon the return of utility power.
Adjustable Voltage-Transfer Points Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Adjustable Voltage Sensitivity Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
UPS - external
AC 120 V
Input Voltage Range
AC 82 - 144 V
Input Voltage Range (Adjustable)
AC 75 - 154 V
47 - 53 / 57-63 Hz
1 x power NEMA 5-20
Power Output Connectors Details
8 x power NEMA 5-15 ¦ 2 x power NEMA 5-20
AC 120 V ± 5% - 47 - 53 / 57-63 Hz
1.98 kW / 2200 VA
Surge Energy Rating
Run Time (Up To)
6.7 min at full load ¦ 24.1 min at half load
Remote Management Interface
Expansion / Connectivity
1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x USB ¦ 1 x EPO (emergency power off)
1 (total) / 1 (free) x SmartSlot
1 x serial cable - external ¦ 1 x USB cable - external ¦ 1 x power cable - integrated - 6 ft
Audible alarm, emergency power off, LCD display
CSA, UL 1449, UL 1778, RoHS Exemption 7b, FCC Part 15 A
Software / System Requirements
Drivers & Utilities
Service & Support
3 years warranty
Service & Support Details
Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years
